If you still have a large collection of CDs and really want to hear exactly what is stored on them we can’t think of a better way to do it at this price level than this TEAC. It is superbly made and a real pleasure to use.
This TEAC-original CD drive mechanism reduces rotation vibration of the disc itself as well as unwanted mechanism vibration by clamping the CD to an aluminum turntable with the same diameter and maximizing inertial mass in order to stabilize rotation. Servo current is reduced with the turntable by correcting disc warping and distortion and improving the relative optical axis precision of the pickup and disc pit side. This realizes reduced disc reading errors and creates outstanding audio quality.
The bridge that supports the turntable is built with carefully-selected lightweight materials that are very rigid and do not transmit vibration.
The entire CD mechanism is mounted on the sub-chassis in a semi-floating state to reduce vibration from the main chassis as well as external vibrations.
CD section
Supported Media
Audio CD, CD (CD-R/CD-RW * CD-DA format)
(8cm CDs not supported)
Digital outputs
COAXIAL
Connector
RCA x1
Output level
0.5Vp-p
Output impedance
75Ω
OPTICAL
Connector
TOS (JEITA RC5720C) x1
Clock sync input
Connector
BNC x1
Input frequency
10MHz
Input impedance
50Ω
Input level
Rectangle wave: equivalent to TTL level,
Sine wave: 0.5 to 1.0Vrms
External control
Trigger input (12V TRIGGER IN)
Connector
3.5mm Mono mini jack x1
Input level
12V, 1mA
Trigger output (12V TRIGGER OUT)
Connector
3.5mm Mono mini jack x1
Input level
12V
Maximum current supply
100mA
General
Power
AC 120V, 60Hz
AC 220-240V, 50/60Hz
Power consumption
40W
Standby power
0.4W
Overall dimensions
444 x 111.3 x 333mm (including protrusions)
Weight
10.1kg
Operating temperature
+5℃ to +35℃
Operating humidity
5％ to 85％ (no condensation)
Storage Temperature
range −20℃ to +55℃
Accessory
AC cord x1, Remote (RC-1338) x1, Dry battery (AAA) x2, Foot pad x3, Manual x1
