Specifications

Analog Inputs: XLR (balanced), RCA (unbalanced)

Input impedance

20 kΩ

Input trimming

0 dB to -5.5 dB in 0.5 dB steps

Input sensitivity

8 dBu

Loudspeaker Outputs: Binding posts with 4 mm ø cable hole (screwable) and banana plug

Output power (RMS, 2 Ω)

2 x 420 W

Harmonic distortion (1 kHz, 2 Ω)

< 0.07 %

Output power (RMS, 4 Ω)

2 x 370 W

Harmonic distortion (1 kHz, 4 Ω)

< 0.06 %

Output power (RMS, 8 Ω)

2 x 200 W

Harmonic distortion (1 kHz, 8 Ω)

< 0.04 %

Output voltage (Peak-to-Peak)

112 V

Output voltage (RMS)

40.2 V

Output impedance (20 Hz – 20 kHz)

< 0.035 Ω

Frequency range (-3dB)

10 Hz – 80 kHz

Amplification gain

26 dB

Damping factor (1 kHz, 8 Ω)

> 280

Noise (A-weighted)

-123 dB

Internal Linear Power Supply with Shielded Toroidal Transformer

Toroidal transformer

866 VA

Operating voltage (Input stage)

+/- 60 V

Operating voltage (power stage)

+/- 64 V

Operating voltage for relays, LEDs, AMP CTL

+ 12 V

Mains Power Supply

Mains voltage (selectable, see fuse chamber)

230 V AC / 50 Hz; 115 V AC / 60 Hz

Fuse 230 V

T 4 A

Fuse 115 V

T 8 A

Power consumption

max. 900 VA

Idle power consumption

20 W

Stand-by power consumption

< 0.3 W

Dimensions & Weight

W x H x D (width x height incl. feet x depth)

278 x 114 x 345 mm

11 x 4.5 x 13.6 inch

Unit weight

14.6 kg

32.2 lbs

Shipping weight

15.8 kg

34.4 lbs
