Physical Specifications

Dimensions8.5″W x 13.9″W x 2.5″H (2.2 w/o Feet)Weight11.7 lb

Material: Machined Aluminum Chassis

Front Panel Display: 3″ AMOLED

Technical Specifications

Power Supply1x50W (CPU)

CPU: Intel Low Power Dual Core

RAM: 8GB

Library Storage Capacity: 2X 2.5″ Compartments (User-Installable Storage)SSD for System & Cache240GB NVME: Data USB Ports2X USB 3.0 (Rear)Software Suite

Aurender Conductor: Ethernet Port

Double-Isolated Gigabit LAN

Uninterruptible Power Supply (UPS): Yes (Super Capacitors)

Power Consumption: Play (12W), Peak (32W), Standby (4.2W)CD Ripping Capability
N/A

Audio Specifications

Analog Outputs: N/A

DAC Chipset: N/A

Audio Word Clock: TCXO

Analog Outputs Supported Format: N/A

Digital Outputs: USB Audio (Dedicated)USB Output

Supported Format: PCM up to 768kHz, DoP up to DSD256, up to DSD 512 Native for USB output

SPDIF & AES/EBU Output Supported Format: N/A

Digital Inputs: N/A

Headphone Section: N/A

Master Clock Input: N/A

MQA Support: MQA Core-Decoder Upgrade Available

Compatible Formats: DSD (DSF, DFF), WAV, FLAC, AIFF, ALAC, M4A, APE and others

DSD-to-PCM Conversion: N/A
