AUDIO SPECIFICATIONS

Number of Channels2

Fixed Output Level2.0Vrms Unbalanced4.0Vrms Balanced

Variable Output LevelN/A

Output Impedance100 ohms Unbalanced and Balanced

Frequency Response±0.5dB from 20Hz-20kHz

Signal To Noise RatioBetter than 100dB (A-weighted)

Dynamic RangeBetter than 96dB

Total Harmonic Distortion0.02% @ 1000Hz

Channel SeparationBetter than 85dB (1,000Hz)

Headphone Output ImpedanceN/A

DIGITAL AUDIO SPECIFICATIONS

Digital-to-Analog Converter (DAC) Type8-channel, 32-bit PCM/DSD, Quad Balanced

Coaxial Sample Rate16, 24-bit/192kHz

Optical Sample Rate16, 24-bit/192kHz

USB Sample Rate16, 24-bit/192kHzNative DSD and DoP DSD Up to DSD256, DXD384

Digital Coaxial Input0.5V p-p/75 ohms

Digital Optical Input-15dbm to -21dbm

Digital Output Sample RateN/A

Digital Optical OutputN/A

Digital Coaxial OutputN/A

Digital Output JitterN/A

Digital XLR OutputN/A

Digital MCT OutputN/A

CONNECTIVITY

Balanced Fixed Output1

Unbalanced Fixed Output1

Balanced Variable Output0

Unbalanced Variable Output0

Digital Coaxial Input2

Digital MCT Input0

Digital Optical Input2

Digital USB Input1

Digital USB Input TypeType B

Digital Coaxial Output0

Digital MCT Output0

Digital Optical Output0

Digital XLR Output0

Headphone Output0

CONTROL

Power Control Input1

Power Control Output1

Rear Panel Data Input1

Rear Panel IR Sensor Input1

RS232 Control Input0

GENERAL SPECIFICATIONS

Disc FormatsSACD, CD, CD-R/RW and DVD-R; popular file formats such as AAC, AIFF, ALAC, DSD (up to DSD128), FLAC, MP3, WAV (up to 24-bit/192kHz) and WMA

Disc Capacity1

Laser TypeTwin Beam

Laser Beam Wavelength650nm (SACD)790nm (CD)

Laser PowerCLASS IIa/CLASS I

Standby Power Requirement<0.5 watt

WEIGHTS & DIMENSIONS

Unit Dimensions (W x H x D)12-5/32" (30.9cm) x 7-3/4" (19.7cm) x 16-1/4" (41.3cm)

Unit Weight20.5 lbs (9.3 kg)

Shipping Weight27.5 lbs (12.5 kg)
