Specifications

Analog & Outputs: XLR (balanced), RCA

Maximum output gain

32.5 dBu

Output impedance

75 Ω

Frequency range (-3 dB)

10 Hz – 300 kHz

Crosstalk (1 kHz)

-108 dB

THD & N (0 dBu, 10 Hz – 22 kHz)

0.001001 %

Noise (A-weighted)

-102.3 dBu

Dynamic range

135 dB

Digital Inputs, DAC768

AES/EBU (XLR), PCM sample rates

44.1/48/88.2/96/176.4/192 kHz

Coaxial SPDIF (RCA), PCM sample rates

44.1/48/88.2/96/176.4/192 kHz

Optical SPDIF (Toslink F 06), PCM sample rates

44.1/48/88.2/96/ with Glass fibre <1m 176.4/192 kHz

USB (B), PCM sample rates

44.1/48/88.2/96/176.4/192/352.8,384/705.6/768 kHz

USB (B), DSD over PCM (DoP), sample rates

2.8 (DSD64), 5.6 (DSD128), 11.2 (DSD256) MHz

0 dBFS calibrated to

15 dBu

Internal Linear Power Supply with Shielded Toroidal Transformer

Operating voltage for analog audio

+/- 60 V

Operating voltage for relays and LEDs

+ 12 V

Mains Power Supply

Mains voltage (selectable, see fuse chamber)

230 V AC / 50; 115 V AC / 60 Hz

Fuse for 230 V

T 500 mA

Fuse for 115 V

T 1 A

Power consumption

max. 40 VA

Stand-by power consumption

< 0.3 W

Dimensions & Weight

W x H x D (width x height incl. feet x depth)

11 x 2.24 x 11.81 inch

Unit weight

6.95 lbs.

Shipping weight (incl. packaging)

11.79 lbs.
